Accordion Doors

The perfect solution for spaces where a quick acoustic or visual barrier are needed

The SoundGuard Acoustic Accordion Doors are the perfect solution for spaces where a quick acoustic or visual barrier is needed. Schools, offices, meeting rooms and even homes can benefit from the ease of use and acoustic separation that is provided by Unifold’s line of SoundGuard Accordion Doors.

View Brochure
SoundGuard 34 SoundGuard 40
Panel Thickness 9mm 12mm
Panel Width 145mm
Structure MDF
Finishes Timber Veneer, Vinyl or Laminates
Hinges Continuous UV-Stabilised PVC
Wheels Nylon coated Ball Bearing
Track Extruded Aluminium Track – Top supported
Track Size 210mm x 38mm
Seals 3 Ply Vinyl 2 Ply Vinyl & Rubber
Hardware * Aluminum Handles, Latch
Lock Whitco 860317 (Optional)
STC Raing 34 40
Stack Depth Approx. 12% of opening width 15% of opening width
Weight 20kg/m² 25kg/m²
Max. height 3670mm
Max. Opening No restriction
Use Commercial

All our Accordion Doors are custom made to suit your desired requirements although as a standard finish, you can choose from our wide range of vinyl colours. We have featured finishes such as magnetic whiteboard and pinboard or you can even find your own textile fabric that suits your space and we will fit it to your wall. In the case of requiring a higher Rw rating, acoustic fabric is preferred.

Click here to view our standard colour ranges:



Pacifica Vinyl

Unifold Timber Grain Vinyl

Unifold Vinyl

Our aluminium track and frames are supplied standard as natural anodised. If required, we can also have these powder coated to your desired colour for a professional high end finish to your wall.
